Terminal Connector
XPE Type Terminal Black
Technical Data:
● Enviromment temperature: -40℃~ +150℃
● Rated voltage : 250V
● Rated current: 5A
● Withstand voltage: Ac2500V / 1min
● Insulation resistance: 500MΩ / PC500V
Materials:
● Insert: Stainless steel
● Insulation body: PA, PP
Item | No. of poles | Wire range | Wire strip length | Color |
XPE012-01 | 1 | 0.5~2.5mm2 | 7~8 / 0.31" | White |
XPE012-02 | 2 | 7~8 / 0.31" | White | |
XPE012-03 | 3 | 7~8 / 0.31" | White | |
XPE012-04 | 4 | 7~8 / 0.31" | White | |
XPE012-05 | 5 | 7~8 / 0.31" | White | |
XPE012-06 | 6 | 7~8 / 0.31" | White | |
XPE012-12 | 12 | 7~8 / 0.31" | White |
