Terminal Connector
ACN442 Type Terminal Connector
● Rated voltage:400V
● Rated current:32A
● Voltage resistance: 2.5KV
● Operating Temperature:-30°C~+105°C
Up to 4mm²
Item | Wire range | Connecting | Wire strip | |
Flexible wire | Non-flexible wire | |||
| ACN-442 1Pole | 0.2~4.0mm² (24-12AWG) | 0.5~2.5mm² (20-14AWG) | 1 | 10/0.39" |
| ACN-442 2Pole | 2 | |||
ACN-442 3Pole | 3 | |||
| ACN-442 4Pole | 4 | |||
| ...... | ...... | |||
| ACN-442 30Pole | 30 | |||
Note: Number of poles can be expanded as needed
● Rated voltage:400V
● Rated current:41A
● Voltage resistance: 2.5KV
● Operating Temperature:-30°C~+105°C
Up to 6mm²
Item | Wire range | Connecting | Wire strip | |
Flexible wire | Non-flexible wire | |||
| ACN-662 1Pole | 0.2~6.0mm² (24-10AWG) | 0.5~4mm² (20-12AWG) | 1 | 12/0.47" |
| ACN-662 2Pole | 2 | |||
ACN-662 3Pole | 3 | |||
| ACN-662 4Pole | 4 | |||
| ...... | ...... | |||
| ACN-662 30Pole | 30 | |||
Note: Number of poles can be expanded as needed
