Terminal Connector
NTB-A Type But Rail Terminal Connector
● Rated voltage：690V
● Rated current:Main wire:41A
● Branch wire: 24A
● Rated Impulse voltage: 4kV
● Operating Temperature: -40°C~+105°C
● Body color available
| Item No. | Wire range | Connecting wire numbers |
Pitch
(mm) |
Wire strip length (mm/in) | ||
| Flexible wire | Non-flexible wire | In | Out | |||
| NTB-A01 |
0.5~6.0mm² (20-10AWG)
0.5~10mm² (20-8AWG) |
0.2~4.0mm² (24-12AWG) |
1 | 1 | 5.15 |
8-10 (0.32"-0.39") |
| NTB-A02 |
2 |
2 | ||||
| NTB-A03 | 3 | 3 | ||||
| NTB-A04 | 4 | 4 | ||||
| ...... | ...... | ...... | ||||
| NTB-A12 | 12 | 12 | ||||
