Heat-shrinkable Tube

HTS Type Heat-shrinkable Tube

HTS Series radiation cross-linking low temperature resistance fire tube has function of excellent insulation, age-resistance and softness, has the c haracteristics of fireresistance and shrinkable temperature of 125℃, which can be done by high heat hairdryer.They are widely used in communication, electronic, aviation and war industry and other fields for wiring insulation, water resistion, wet resistion and airproof, etc.
Standard color: Black, White, Red, Yellow. Blue, Green, Grey.

Item No .SizeDimension before
shrinking (mm)
Dimension after
shrinking (mm)
Length
Per
Roll
(mm)
Internal
diameter
Max internal
diameter
Wall
thickness
HTS-11.0/0.51.0±0.30.5±0.10.25±0.01200
HTS-1.51.5/0.751.5±0.30.75±0.10.25±0.01200
HTS-22.0/1.02.0±0.31.0±0.10.25±0.01200
HTS-2.52.5/1.252.5±0.31.25±0.10.25±0.01200
HTS-33.0/1.53.0±0.31.5±0.10.30±0.01200
HTS-3.53.5/1.753.5±0.31.75±0.10.32±0.01200
HTS-44.0/2.04.0±0.32.0±0.10.34±0.01100
HTS-4.55.0/2.55.0±0.32.5±0.20.46±0.01100
HTS-66.0/3.06.0±0.43.0±0.20.46±0.01100
HTS-77.0/3.57.0±0.43.5±0.20.46±0.01100
HTS-88.0/4.08.0±0.44.0±0.20.48±0.01100
HTS-99.0/4.59.0±0.44.5±0.20.52±0.01100
HTS-1010.0/5.010.0±0.45.0±0.20.52±0.01100
HTS-1111.0/5.511.0±0.45.5±0.20.52±0.01100
HTS-1212.0/6.012.0±0.46.0±0.30.24±0.01100
HTS-1313.0/6.513.0±0.46.5±0.30.26±0.01100
HTS-1414.0/7.014.0±0.47.0±0.30.26±0.01100
HTS-1515.0/7.515.0±0.47.5±0.40.62±0.01100
HTS-1616.0/8.016.0±0.58.0±0.30.62±0.01100
HTS-1717.0/8.517.0±0.58.5±0.30.63±0.0250
HTS-1818.0/9.018.0±0.59.0±0.30.70±0.0250
HTS-2020.0/10.020.0±0.510.0±0.30.72±0.0225
HTS-2222.0/11.022.0±0.511.0±0.30.75±0.0225
HTS-2525.0/12.525.0±0.812.5±1.00.80±0.0225
HTS-2828.0/14.028.0±0.814.0±1.00.80±0.0225
HTS-3030.0/15.030.0±0.815.0±1.00.82±0.0225
HTS-3535.0/17.535.0±0.817.5±1.00.82±0.0225
HTS-4040.0/20.040.0±1.520.0±1.00.82±0.0225
HTS-4545.0/22.545.0±1.522.5±1.00.82±0.0225
HTS-5050.0/25.050.0±1.525.0±1.00.82±0.0225
HTS-6060.0/30.060.0±1.530.0±1.50.92±0.0225
HTS-7070.0/35.070.0±1.535.0±1.50.95±0.0225
HTS-8080.0/40.080.0±1.540.0±1.50.95±0.0225
HTS-9090.0/45.090.0±1.545.0±1.51.10±0.0225
HTS-100100.0/50.0100.0±1.550.0±1.51.10±0.0225
HTS-120120.0/60.0120.0±1.560.0±1.51.10±0.0225
HTS-150150.0/75.0150.0±1.575.0±1.51.15±0.0225
HTS-180180.0/90.0180.0±1.590.0±1.51.15±0.0225
HTS-200200.0/100.0200.0±1.5100.0±1.51.15±0.0225
